实验室型沸腾制粒干燥机

  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
  • 实验室型沸腾制粒干燥机
型号︰FL-5
品牌︰-
原产地︰中国
单价︰-
最少订量︰1 件
分享到:

 共有 8 相关信息
上一个12345下一个

产品描述

.jpg

—Description

The method of boiling and granulating is a comprehensive fruit of spraying and fluidizing technology. It makes traditional mixing ,granulating and drying processes finish in the same closed container. So it is called as "one step granulator".

This machine has simple structure and is easy to clean and maintain .Not only it can make granule but also dry quickly. The process of mixing ,granulating ,drying will be finished in the same closed container at the same time. So it can prevent from pollution caused by contacting with environment and guarantee that the quality of medical granule is conformity with the requirement of "GMP".
The parts contacted with raw material are made of 316L stainless steel. The heating of machine can be divided into electricity or steam and the control part can be divided into ordinary form or computer form .Customer can choose it freely

—Installation Diagram2018-09-27_104123.jpg



—feature—

•.Improve its fluidity and reduce powder dust to fly through powder granulating.

Improve its solving property through powder granulating

•.Mixing, granulating and drying can be finished in the same machine, i.e .one step to granulate.

Being adapted anti-static electricity filtering cloth, the operation of equipment is safe.

Being set discharge hole of pressure, if explosion were taken place, the equipment and personal can not be

damaged.

Automatic operation, or hand operation.

•.There is a bleed hole, once explosion, this machine cant be damaged.

•.Guard against electrostatic generation, adopt the cloth bag without electrostatic.

The equipment has no dead corner. The loading and unloading is quick and convenient. It can be washed

Clean .It is in conformity with the normal of GMP



technical parameters

  • Improve its fluidity and reduce powder dust to fly through powder granulating.
  • Improve its solving property through powder granulating
  • Mixing, granulating and drying can be finished in the same machine, i.e .one step to granulate.
  • Being adapted anti-static electricity filtering cloth, the operation of equipment is safe.
  • Being set discharge hole of pressure, if explosion were taken place, the equipment and personal can not be

damaged.

  • Automatic operation, or hand operation.
  • There is a bleed hole, once explosion, this machine cant be damaged.
  • Guard against electrostatic generation, adopt the cloth bag without electrostatic.
  • The equipment has no dead corner. The loading and unloading is quick and convenient. It can be washed

Clean .It is in conformity with the normal of GMP.



—Technical Specifications

Main machine is made of 316L stainless steel, 3 mm in thickness, inside surface adopts mirror polish, no dead corner, cleaning is very easy; outside surface adopts matte finishing.

 Hopper capacity: 12 liters

A charging wagons is equipped, material: 316L stainless steel

 Production capacity for main machine: 1 – 5 kg/batch

 Granulating time: 60 – 90 minutes/batch, 4 batchs/8 hours

 Working temperature: 50 -  120 °C

Heating type :  electric heating, SUS 304 stainless steel tube with 18 x 2 stainless steel fin,  Power : 9 KW

 Noise snubber is equipped in the centrifugal fan.

Bag filter, 2 sets ; vibrating cylinder, 2 sets ; valve for air adjusting, 2 sets.

 Peristaltic pump, 1 unit, BT-50S

 Spray gun, 1 pc ;  base of spray gun, 2 pcs ;  3 fluid type, the height of spray gun can be adjusted.

 Ventilating system adopts primary effect, middle effect and sub-high effect filters, ensure hundreds of clean air.

Air filter box, 1 unit, with primary effect, middle effect and sub-high effect filters.

Air drive fast valve at the air inlet, avoid the heat loss.

 Control cabinet, Material :  304# stainless steel, PLC control, touch screen operation.

Main electrical components: Siemens, Germany

 Overall size: 2800 mm x  700 x 2200 mm

Equipped Electrical Apparatus Components List

No.

Apparatus Name

Specification

Supplier

Qty

1

Upper cylindrical

316 L, 3 mm in thickness

Company

1

2

Middle cylindrical

316 L, 3 mm in thickness

1

3

Charging wagon

316L stainless steel

1

4

Braket

316L stainless steel

Company

2

5

Hopper

316L stainless steel

company

1

6

Bag filter

Antistatic cloth

Company

2

7

Primary effect filter

SUS 304#

Company

1

8

Middle effect filter

Non-woven fabrics

Company

1

9

High effect filter

Non-woven fabrics

SUJING, Changzhou

1

10

Frame of filter

SUS 304#

Company

1

11

Air shutter

SUS 304#

Company

3

12

Air shutter

SUS 304#

Company

1

13

Cylinder

316L stainless steel, QGB100 x 100-MF2

Hualong, Wuxi

2

14

Cylinder

316L stainless steel, QGB63 x 200-MP4

Hualong, Wuxi

2

15

Cylinder

316L stainless steel, QGB63 x 250-MF1

Hualong, Wuxi

3

16

Draught fan

3  KW, Explosion-proof motor

Sufeng, Wuxi

1

17

Frequency converter

3  KW

Dr. Lishile

1

18

Pipeline

SUS 304#, 1.5 mm in thickness

Company

1

19

Flange

SUS 304#, 14 mm, 16 mm and

20 mm in diameter

Company

1

20

Chimney

A3, 1.5 mm in thickness

Company

1

21

Silencer

A3, 1.5 mm in thickness

Company

1

22

Bolt

SUS 304#

Company

1

23

DN25 filter

Copper

Jiangyin, Jiangsu

1

25

Control cabinet

PLC control, touch screen operation.

Company

1

26

Pressure regulating valve

R3000

AIRTAC

4

27

Separator of filtration of

water

F3000

AIRTAC

2

28

Lubricator

L3000

AIRTAC

2

29

Integrated package

Magnet valve

AC24V

AIRTAC

2

30

Pneumatic magnet valve

6 pcs, 1 double control ;

5 single control

AIRTAC

1

31

Hot resistance

Pt100

Shanghai

2

32

Peristaltic pump

BT 50S

Baoding

1

Remark: The final components are subject to the function and requirement of your needed machine.



Our advantages

Products advantages

1. We always give top priority to quality

2. Strictly guarantee the precision of parts error

3. Reasonable processing technology coupled with advanced processing equipment

Trade advantages

1.Our company is a Gold Supplier on Alibaba. So we can       provide Escrow Service on Alibaba.

2.Our company can do Trade Assurance Order for customers    on Alibaba.

Custom made advantages

1.The company independent research and development, custom design exclusive for the series of products.

2. Mutual benefit with the best quality and service, and sincerely hope that friends from various circles at home and abroad sincere cooperation and mutual benefit and win-win situation.

Company Introduction

——Our Company

2018-07-17_171953

 Flight Pharmaceutical Machinery CO., Ltd is the professional manufacturer and export of

various pharmaceutical machineries in China. Our company has profuse designs with series

quality grade, and expressly, our price is very competitive, because we are manufactory.

  Our factory developed about forty types of machines in over ten varieties. By ISO9001:2000

quality system attestation, accord with GMP attestation request. All tasks from casting to

metal machining, and general assembly are accomplished ourselves.

  We produce and export various pharmaceutical machineries, relevant medicament detecting

instruments and packing machinery, such as Rotary tablet press, Single punch tablet

press, Pulverizer, Mixer,Coating machine, Granulator, Labeling machine, Liquid filling

machine, Capsule filing machine, Blister packing machine, and so on.

  We have professional export office, with an experienced and professional team, they will

service in whole business. By excellent quality, reasonable price and perfect after-service,our

products have been sold in many countries and regions all over the world, Such as United

States, Canada, Australia, United Kingdom, Bulgaria, Russia, Indonesia, Pakistan, Thailand

and Vietnam etc, these products are very popular with the customers there.



 Try to do everything, let customer satisfaction, this is our company’s service tenet.



Buying Guides

——Our Customer——





Certificate


  ——Packing & Shipping——


Delivery time

Within 30 days after receiving the payment.

Payment methods

T/T or Western Union payment, and full payment before shipping

Guarantee

One year quality guarantees and free with spare parts for one year.

After sales service

The English user manual Circuit diagram

价格条款︰FOB Shanghai
付款方式︰TT
包装︰胶合板木箱
交货期︰15 个工作日
质量/安全认证︰ISO CE
